If you have trolling motors but you have no knowledge about them then it may be difficult for you to wire the trolling motor. Only a guide or set of instructions can help you to u complete this wiring task effectively.
Here is a quick guide that will help you to do the wiring process of the trolling motor without any error. It will also help you to wire a trolling motor safely. So be ready to focus on it.
Safety is important
Safety should be considered first when you working with dangerous materials. Remember, you should be safe to use the batteries to run the how to hook up a 24v trolling motor off the boat. It is safe to use enough battery capacity required for the boat because the more voltage of the battery may potentially burn or blast and destroy the boat too.
You can make use of the circuit breaker when you use more than one battery. In the case of an accident or fault on the motor, the receiving of electric power from the battery is been cut by the trolling motor.
Steps to wire the 24v trolling motor
Two 12-volt batteries are often required to wire a 24-volt trolling motor. This means you’ll need to connect the two batteries before connecting them to your power source to operate the trolling motor.
You should also test the batteries before how to hook up a 24v trolling motor them to your motor to confirm that they are fully charged. When testing, keep in mind that the negative battery terminals are black and the positive terminals are red. Use this information to properly position your meter for the most accurate readings.
When connected in series, your batteries should have a resting voltage of 12.7 and a voltage of roughly 25.6. If your readings are lower than these figures, you should think about changing the batteries.
When utilizing more than one battery, you should consider using a circuit breaker. This can assist to safeguard your motor if it becomes trapped on anything underwater, for example.
Organize the batteries side by side. Battery one’s positive terminal should be near battery two’s negative terminal. The trolling motor should be linked directly to the circuit breaker. The positive lead of the motor should be connected to the positive terminal of the circuit breaker.
Then the negative terminal of the circuit breaker should be connected to the positive terminal of the first battery. Then the batteries should be connected by connecting the negative terminal of the first battery to the positive terminal of the second battery.
Then you can connect the negative terminal of the second battery to the negative lead of the trolling motor
Covering up
Knowing how to connect your trolling motor might come in handy if something goes wrong or if you need to convert to a new system. It can also allow you to connect additional plug systems to make switching between batteries and gadgets even easier, which means you only need to hook your gear up once for each item you use.
Remember to consider safety before attempting to connect your engine. If you have any doubts regarding your power connections, it is recommended to get expert help.
